Factory Automatic Feeding 10-30 T/H Dry Mix Mortar Plant Prices for Sale
1. Description Of MG Automatic Dry Mix Mortar Plant:
The main components of this production line: raw material storing system, automatic weighing system, conveying system, mixing system, pneumatic system, packing system and dedusting system. the main control system administrate the production order based on fixed formula ratio, thus the production line will dosing the coarse materials from storage silos, after automatic weighing, the material will enter in premix tank and high efficient agravic mixer continuously, to mix in a short period(3-5min).The well mixed material will discharge into the holding tank, which will make secondary mixing, then down to new designed automatic filling and packing machine, the packing machine work efficiently based on fixed time and volume, it increase the capacity sharply, well packed finished mortar will be transferred to finished mortar area, ready for sale.
2. Configuration Of MG Full Automatic Dry Mix Mortar Plant
- 1. Aggregates storage bins, powder materials silos.
- 2. Screw conveyors, weighing scales
- 3. Bucket elevators
- 4. Full automatic batching system
- 5. Pre-mixing bin
- 6. Mixer(Installed with triaxial mixing vanes)
- 7. Finished products storage bins
- 8. Packaging system (Open gate/valve-gate type packing machine)
- 9. Dust removal system(impulse type)
- 10. Control system to inspect the level of powder materials
- 11. Steel frame, platform, ladder stand, barrier
- 12. Main control system
- 13. Air compressor system: The central air compressor
- 14. The gas phase equilibrium system
- 15. Bulk materials storage system: finished mixture tanks, bulk machine.
- 16. Drying system
- 17. Alarm system
3. Parameter of MG Full Automatic Dry Mix Mortar Plant:
| Model | 2000L Mixing plant | 3000/4000L Mixing plant | 6000L Mixing Plant | 10000L Mixing Plant |
| Capacity | 10-12T/H | 15-30T/H | 30-40T/H | 50-60T/H |
| Machine Height | 8-9m | 9-10m | 11-12m | 13-15m |
| Total Power | 80-90KW | 90-100KW | 100-120KW | 120-150KW |
| Worker Required | 2-3 person | 3-4 person | 3-4 person | 3-4 person |
| Workshop Required | 500-600㎡ | 600-800㎡ | 800-1000㎡ | 1000-1500㎡ |
| Bag belt Conveyor | B500X5000mm | B500X5000mm | B500X5000mm | B500X5000mm |
| Pallet Wrapping Machine | Provide | Provide | Provide | Provide |
| Sand Dryer | Provide As Requirement | Provide As Requirement | Provide As Requirement | Provide As Requirement |
| HS Code | 8474390000 | 8474390000 | 8474390000 | 8474390000 |
4. Advantage of MG Automatic Dry Mix Mortar Plant:
(1)There are several materials discharging modes for selecting, which include the manual mode, electrical mode and pneumatic mode.
(2)The fiber can be rapidly separated by the high speed rotating blades.
(3)The air-phase balancing device is installed to mix the materials more even.
(4)The compound structure of paddles can largely reduce the cost of maintenance.
(5)The materials are discharged through the big gate, which can reduce the blind areas inside the mixer, make the discharging procedure cleaner and faster.
(6)It can mix the solid-solid (powder and power) and solid-liquid (powder and liquid), and also take drying operation.
(7)The speed of mixing is fast, it only takes about 2-3 minutes to mix the ordinary powders.
(8)The machine can be operated in confined space, which is running reliably and convenient in maintenance.
5. Application of MG Automatic Dry Mix Mortar Plant:
The dry mortar production line can produce the following dry mortars:
Bonding mortar: Masonry mortar, wall and floor tile adhesive mortar, anchorage mortar etc.
Decoration mortar: Decorative plaster, inner and outer wall putty, colorful decoration mortar etc. Protection mortar: Water-proof mortar, anti-corrosion mortar, self-leveling mortar, wear resistance mortar, thermal insulation mortar, sound insulation mortar, repair mortar, mildewproof mortar, shielding mortar etc.
6. Factory and Workshop
7. Certificates
8. Our Company
Zhengzhou MG industrial Co., Ltd, the leader of Full Automatic dry mix mortar plant!
Zhengzhou MG industrial Co., Ltd, was verified by ISO9001 quality control system, awarded as Henan first-class science and technology enterprise by government. We were Henan observe quality and credibility enterprise union governing unit in 2012.
Our company engaged in the dry powder mixing equipment R&D, production, sales and construction, providing most efficient turnkey solutions to our clients in green building energy-saving insulation and green wall (building) materials manufacturing equipment, production technology and construction program.
Our main products include dry mortar production line, thermal insulation mortar production line, sand dryer, powder blending machine, concrete mixer, and others.
9. Our advantages :
1. Leading position in this industry--With decades years development and creation, we enjoy a high reputation and outstanding position in this trade since 2000.
2. Excellent quality guaranteed-Our machine exported to over 20 countries and regions because of the good quality.
3. Rich successful experience in complete production line-- with successful installation production experience of thousands of sets of equipment, provide you with a wide selection of investment and construction program.
4. Comprehensive and professional services-provide our clients with turn-key services from supplying raw materials, formula, equipment, installation, to heart-felted after-sale services, escort your success in one stop station!
